Centauri Carbon 2 Servo Motor Detection PCB –50.204.0302

This is a strain-gauge-based sensor that lives under the heated bed. Unlike the “short wire” versions that plug into closer junction points, the “long wire” variant is designed to reach the primary Strain Gauge Adapter Board (50.204.0304) from the furthest corners of the bed.

Specifications

Wire Length: Approximately 225mm

Type: Analog Pressure Sensor (Strain Gauge)

System Role: Detects the physical “tap” of the nozzle against the build plate to calculate the Z-offset and 121-point mesh.
