This filament is highly abrasive, we strongly recommend printing with Tungsten Carbide Nozzle like theUndertakerFeed your Printer the Filament of the Gods.Manufactured to a tighter than standard tolerance (+/- 0.03mm) you'll experience consistent extrusion
This filament is highly abrasive, we strongly recommend printing with Tungsten Carbide Nozzle like theUndertaker
Feed your Printer the Filament of the Gods.
Manufactured to a tighter than standard tolerance (+/- 0.03mm) you’ll experience consistent extrusion throughout the spool.
PPS-CF (Polyphenylene Sulfide – Carbon Fiber) filament offers superior industrial performance over standard materials like ABS, featuring extremely high heat resistance, exceptional chemical resistance, high stiffness, and low moisture absorption. It is a high-performance material ideal for harsh environments, providing superior dimensional stability, reduced warping, and greater strength, making it suitable for automotive and aerospace applications..
Check out our other lines of Ambrosia Filament!
| ASA | ASA-CF | ASA Sparkle | ASA Dolos | ABS+ | PETG | PLA |
|
PLA Dolos |
PC-ABS | PC-CF | TPU | ABS Matte | ASA-GF | PLA-SILK |
|
PHA |
PPS-CF |
Ambrosia Filament’s Recommended Print Settings for our PPS-CF filament:
| Attribute | AcceptedValue(s) [Our Recommended Value] |
| Extruder Temperature | 300-350 Degrees Celsius [340] |
| Heated Bed | 90-110 Degrees Celsius [100] |
| Build Surface | PEI, Buildtak, or similar surface [Textured PEI] |
| Cooling Fan | 0-40% range varies by cooling capabilities |
| Environmental Temperatures | 40-120C [70C] |
| Soluble Support Materials |
Technical Specifications for our PPS-CF Filament:
| Physical Properties | Test Methodology | Values |
| Density | ISO1183 | 1.3-1.31 g/cm^3 |
| Melt Flow Rate (250C/2.16KG) | ISO 1133 | 3-6 g/10min |
| Mechanical Properties | Test Methodology | Values |
| Tensile Strength | ISO 527 | 100-110 Mpa |
| Elongation at break | ISO 527 | 1-3% |
| Flexural Modulus | ISO 527 | 5500-6000 Mpa |
| Flexural Strength | ISO 178 | 170-180 Mpa |
| Impact Strength | ISO 180 | 25-30 KJ/m^2 |
| Thermal Dynamic Properties | Test Methodology | Values |
| HDT@ 0.455 MPa(66 psi) | ISO 75 | 245C |
Filament can absorb moisture easily.To prevent moisture absorption and contamination, the packing of filament should be kept sealed and in an airtight container with desiccant.
